Therm-O-Plan

Automated Path Planing and Monitoring of Automated-Fiber-Placement-Processes

The Automated-Fiber-Placement (AFP) is one of the leading manufacturing technologies in the field of cost-effective, high-quality serial production of light-weight structures. Nevertheless, both the reliability of the automated production systems and the efficiency of the process planning still offer improvement potential. In addition to the aerospace industry, the automotive industry and other high-demanding lightweight construction industries are pushing further developments.

In the AFP process, pre-impregnated carbon fibers (tows) are placed automatically on a tool surface. Due to recent technological advances in the production technology, increasingly complex components can be realized. However, this progress also leads to a higher complexity of the tools and tool surfaces. Notwithstanding available CAD/CAM-applications, the additional high structural requirements for CFRP laminates require a manual, very time consuming adaptation of the laying path while adhering to strict design rules. In addition to the selected tow paths, the process parameters have a decisive influence on the laying quality. Inadequately pre-heated tool surfaces or deviating compaction pressure can lead to defects such as tows separating from the surface. If the occurring errors are not detected and corrected, deviations from the component’s design and structural requirements occur. In general, the machine operator is responsible for assuring the quality of the product. This is usually done by visually inspecting the individual layers. This approach not only restricts the productivity of the AFP process, but also entails high repair costs for undiscovered errors which need to be corrected at a later stage. In exceptional cases this can lead to the rejection of the entire component.

The „Therm-O-Plan“ project is a cooperation between the Institute of Production Engineering and Machine Tools of the Leibniz Universität Hannover, Automation Technology GmbH and Systemtechnik Ingenieurgesellschaft mbH (SMWS). The aim of the project is to reduce the planning effort for the production of light-weight structures by automated optimized path planning. In addition, the project aims to increase the process reliability of the AFP process by means of online thermographic process monitoring. The partial developments pursued in this process are integrated in a higher-level solution approach and can easily be implemented in conventional AFP process chains.

Funding: Central Innovation Program for SMEs (ZIM)

Duration: 2015-2017

http://www.aucoteam.de/wp-content/uploads/2013/06/ZIM-Logo.jpg



Multi-Matrix-Prepreg

Online-Production of Multi-Matrix-Prepreg in Automated-Fiber-Placement

3.MMPThis project pursues the establishment of an interdisciplinary research focus “individualized CFRP light-weight structures with the aid of flexible manufacturing technologies”. Overall, this research group is based on fundamental research projects as well as application-based research project with industrial partners. The Multi-Matrix-Prepreg (MMP) project is the first step of this local strategy and addresses the area of “material-side flexibility”.

Individualized structures made of fiber reinforced plastics (FRP), in particular carbon-fiber reinforced plastics (CFRP), present a great economic and manufacturing challenge in serial production, e.g. of aircraft (hull, wing, side guide). Future competitiveness of Lower Saxony CFRP industry requires the implementation of new, flexible material, construction and manufacturing concepts. This can lead to a reduction in production costs and enable the production of further function-integrated components using CFRP to an increasing extent. Production sites that are currently producing CFRP components, such as the fuselage of the Airbus A350XWB, can be technologically strengthened for future developments. Novel Material solutions are part of the measures to further exploit the potential of CRFP. The main idea behind the project is to influence component properties by combining different matrix materials in an online impregnation process. The matrix materials can either be duroplastic, thermoplastic or an elastomer. During the online imprenation process the chosen different matrix materials can be combined at a set ratio. By using different matrix materials for one component the impact resistance, crack propagation resistance, weldability, stiffness and strenght of the finished product con be improved severely.

The objective of the collaborative project is to develop, implement and verify methods for the automated and quality-monitored production of multi-matrix laminates with continuous fibers, as well as to demonstrate the resulting application potentials. An innovative interdisciplinary approach is being developed from existing material and production concepts in order to realize MMLs with continuous fiber strands and locally selectively applied thermoplastic, elastomeric or duroplastic matrix material. In this process, the rovings are impregnated and consolidated online and in an innovative AFP tooling module. This is done in accordance to the locally used matrix material, the overall component requirements and taking into account the material-dependent process parameters.

Funding: Niedersächsisches Vorab, Volkswagen Foundation

Duration: 2016-2019

FlexProCFK

Flexible Technologies for Production of individualised CFRP-Structures



This project pursues the establishment of an interdisciplinary research focus “individualized CFRP light-weight structures with the aid of flexible manufacturing technologies”. Overall, this research group is based on fundamental research projects as well as application-based research projects with industrial partners. This project is the second step of this local strategy and addresses the area of “local variant flexibility”

Within the interdisciplinary development process, the implementation of Continuous Wet Draping (CWD) and its assessment is carried out. This process requires a combination of the different core areas of expertise in the fields of structural development, new materials and autumation and production technoloy. The institutes involved in the project are recognized in their field and experienced in overcoming the additional challenges associated with an interdisciplinary collaboration.

The specific tasks to be developed or researched by the different partners are therefore derived from the expertise of the respective partner:[/vc_column_text][/vc_column][/vc_row][vc_row][vc_column][list color=”black”]

  • Development of a method for the implementation of individualization into the integrated structure and production design process (IFL)
  • Development and research of a method and a module for the targeted application of matix systems onto carbon fiber fabrics (PuK)
  • Evaluation of the novel CWD technology for flexible production of inidviualized stiffening structures in the context of the integrated design process of structure and production (IFL)
  • Reasearch and specific manipulation of the draping behavior of carbon fiber fabrics with locally variable properties on complexly curved  surfaces (PuK)
  • Development and research of a method and modules for draping variable carbon fiber fabrics on arbitrary and variable profiles (IFW)
  • Development and research of a method and its modules for the flexible stocking and on-line assembly of semi-finished CFRP products for flexible draping (IFW)

[/list][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]The project „FlexProCFK“ is a cooperation between the Institute of Production Engineering and Machine Tools (IFW) of the Leibniz Universität Hannover, the Institute of Aircraft Design and Lightweight Structures (IFL) of the Technische Universität Braunschweig und the Institute of Polymer Materials and Plastics Engineering (PuK) of the Clausthal University of Technology. The aim of the project is to design and implement an innovative flexible manufacturing technology for the production of individualized CFRP structures. Within the project, Continuous Wet Draping is developed as a new production technology in carbon fiber fabrics are individually impregnated with resin and subsequently draped into complex geometries.

Funding: EUROPEAN REGIONAL DEVELOPMENT FUND (ERDF)

Duration: 2016-2019



ProDesign

Integrated method for process planning and structural design in composite structures

The project’s research hypothesis is that, with an adjusted method, it is possible to develop lightweight structures out of fiber composite material to not only reach low mass properties but also to be efficiently manufacturable. As a consequence, high engineering and production costs compared to metal designs can be reduced.

The objective is to develop and evaluate a method for the automated design of high-performance fiber composite structures and their efficient production. This comprises structural design, production planning and their interaction. The quality of a solution is determined by structural criteria (mass) as well as production criteria (production cost). Compared to conventional methods, an early consideration of production aspects prevents cost-intensive iterations in later stages of the development process. Conventional methods can only select a limited amount of solutions in the concept phase since all of them are to be fully developed in the following development steps. This method, however, is able to consider a higher number of solutions that differ in structural and production aspects. The overall development effort can be limited by gradually proceeding through the design of all solutions in parallel. In the course of this process the complexity of applied design and assessment methods is increased while the number of considered solutions is decreased. Therefore, complex methods are only used for a smaller number of solutions that qualified in preceding selections.

As an application example the development of an aircraft fuselage structure made of carbon fiber reinforced plastic (CFRP) is chosen, since it has extreme requirements that can only be met in an optimum way by using an approach with strong interaction of both disciplines.

The research is based on achievements of an interdisciplinary cooperation of the institutes in the field of high performance production of CFRP-structures practiced since 2010.

Funding: Deutsche Forschungsgemeinschaft (DFG)

Duration: 2015-2018



ROBUFIL

Robust Fiber-Placement Systems for Aerospace Structures

To ensure aviation’s high-capability and efficiency, the (further) development and optimization of production processes, which increase the use of light-weight structures and thus contribute to an environmentally friendly air transport system, is of crucial importance. The ROBUFIL project contributes with the development of a manufacturing facility and related technologies for the automated production of CFRP structures by combining Automated Fiber Placement (AFP) and Automated Tape Laying (ATL) in one component as well as fiber placement with different carbon fiber fabrics. The overall objective of the project is to optimize the processess of fiber placement and tape laying, with a focus on a robust fiber placement process. The Institute of Polymer Materials and Plastics Engineering is particularly working with the material and demonstator design.

At first, a base epoxy resin material is examined. Based on the results of this examination either a bonded dry-tape or a thermoplastic prepreg is examined. A deeper analysis of the starting material and of the laminate resulting form the laying-process with focus on the process parameters allows to determine a practicable model for the process and to optimize the lay-up times. The analysis espcially focuses on the interation of the temperature (heating method and rate) and thus the viscosity of the matrix and the compaction behavior of the material as well as the interaction of the carbon fiber fabric with the surfaces of the conveying system. Additionally, withing the framework of these tests, design methods for components produced in this process are to be developed and evaluated, thus supprting the efficient production of aeronautical components. The technology demonstration at the end of the project aims at transferring the  knowledge establisehd in the laboratory to the fiber-placement system by examinating the influence of the process parameters on the laminate quality directly at the plant.

The ROBUFIL project is a cooperation of the Institute of Polymer Materials and Plastics Engineering at the Clausthal University of Technology, Brötje Automation Composites GmbH and SWMS Systemtechnik Ingenieurgesellschaft mbH and is supported by the German Federal Ministry of Economic Affairs and Energy.

Funding: Federal Ministry of Economic Affairs and Energy(BMWi)

Duration: 2016-2018

csm_01_bmwi_rgb_gef_de_300_600bd75bdc

Join THIS

JoinTHIS – Production and Joining of Large Thermoplastic In-Situ Consolidated Structures

The main goal of the JoinTHIS project is to develop, implement and evaluate a manufacturing methodology based on AFP and welding technologies for thermoplastics, enabling the autoclave-free production of thermoplastic CFRP structures for the next aircraft generation. The new manufacturing method ensures an economically implementation of large-scale structural lightweight construction concepts for aircraft fuselages based on thermoplastic fiber-reinforced materials. . Due to an increasing production and resource efficiency as well as reducing CO2 emissions, the new manufacturing method is making a significant contribution to a sustainable mobility strategy as presented by the European Commission’s FlightPath 2050.

Funding: European Regional Development Fund

Duration: 2018-2021

HP CFK

High-Performance Production of CFRP Structures

Hochleistungsproduktion von CFK StrukturenAs an inter-university research group, we have set the goal for ourselves to develop a comprehensive solution for the economical and reliable production of carbon-fiber-reinforced-plastic (CFRP) components in aviation industry. With this we are aiming for manufacturing properties that meet the requirements of a larg-scale part production of this industry.

Alongside the closed process chain, we set the following sub-targets in our areas of expertise:

In the area of construction methods and structures, more efficient light-weight construction concepts are developd based on and in interaction with materials and process sequences. We are concentrating on robust and reliable manufacturing geometries, taking into account the structural mechanical effectiveness of these parts. The optimization of the construction method includes global, local and tolerance-related parameters.

When it comes to materials, processes and process chains of CFRP component manufacturing, the challenges of future structres must be countered. Especially with regard to high process spees, an increased robustness and effective performance of the system components. Therefore, we are developing new solutions for the material systems; textiles and resins with respect to a process suitable for serial production.

In order to achieve a high-performance production of CFRP structures, a comprehensive plant and process automation is also a prerequiste. We consider draping and tooling systems with a high form-flexibility, which provide both solution approaches to overcome tolerance problems during production as well as high flexibility in the shape design. Process integrated quality monitoring systems also support the high level of automation.

In order to guarantee an economical CFRP production, the entire project is to be accompanied by a cost-effectiveness analysis, taking into accout interactions within the process chain. This is done in addition to the fundamental research of the partial objectives mentioned above.

In addition to these scientific objectives, a didactic objective is pursued with the project. This enables the next generation of scientists to prepare their dissertation in a structured and targeted manner within the institutionalized project group. This includes integrating compentences relevant for the labor market into the doctoral education, such as professional-methodological and social-communicative skills. This increase the employability of the scientific staff. Application-oriented interships as well as industrial research cooperations also help young academics to network with the regional economy and thus strengthen the recognition of the universities involved.

Funding: Ministry for Science and Culture of the State of Lower Saxony, European Regional Development Fund

Duration: 2010-2015
